FBT Subline 112 SA Processed Active Subwoofer 700W

Bass-reflex design with high SPL and punch
320mm (12”) high excursion magnet woofer with 75mm (3”) voice coil
Frequency response from 40Hz to 140Hz
New amplifier engineered and manufactured by FBT, 700W RMS LF in Class D
Digital Signal processor with 8 presets, 2 equalization with 2 LPF Crossover settings, cardioid configuration
Control panel with Stereo XLR in/outs, Volume, EQ presets, 8 steps Delay from 0.25m to 3.5m, Phase Reversal Switch 0°-180°, 3 status LED indicators
15 mm (0.59”) birch plywood scratch resistant enclosure with internal bracing
M20 (20mm) top mount speaker stand socket and two aluminum ergonomic FBT handles
Code:
41223
Configuration:
1 vie
Built-in amplifier LF/HF:
700 W RMS
Built-in amplifier peak LF/HF:
1400 W
Frequency response:
42Hz - 140Hz -6dB
Low Frequency woofer:
12 - 2.5 coil mm
Maximum SPL cont/peak:
129/133 half-space dB
Dispersion:
omnidirectional HxV
Input impedance:
22 Kohm
Crossover Frequency:
90 or 140Hz KHz
AC Power requirements:
640 VA
Input connector:
stereo XLR with loop, HP out
Power cord:
5/16.4 m
Net Dimension (WxHxD):
430x447x480 / 16.9x21.5x18.9 mm
Net Weight:
23./50.7 kg
Transport Dimension (WxHxD):
530x547x580 / 20.9x21.5x22.8 mm
Transport Weight:
27/59.5 kg
